34 Scale Link 2 Technical Manual D4204-EN
MENU 2.1 – SCOREBOARD & OPERATIONAL STATUS MESS. (JUMP LIST 21)
SCOREM (D.A.N. 2101) Scoreboard Modes
There are multiple scoreboard modes available; this feature causes the indicator to continuously send data. No data
is transmitted when SCOREM is set to ‘0'. See pages 11 & 12 for connections.
Refer to D3648 for the most up to date details on scoreboard functions.
0 Disable scoreboard output.
1 Transmit weight displayed once per second.
• Starts with <STX> (Start of Text - Dec. 2).
• Six digit displayed weight value (may include a decimal). Some digits may provide additional
information as follows:
<STX>ABBBCD<CR>
A = either a minus sign, SPACE, number, or a dollar($). The dollar($) appears when the "Lock
On" weigh method and has "locked onto" a weight value.
B = a number or a SPACE.
C = a number, SPACE, or a '-' minus sign indicating a TR command is active.
D = a number or a '-' minus sign indicating that motion is active.
• Ends with a <CR> (Carriage Return- Dec. 13).
Output examples: (Note: Data sent will start with a <STX> and end with <CR>).
" 1530" - Normal weight value.
"- 1530" - Negative weight value.
"$ 1530" - “Locked On” animal weight value.
" 15-0" - Normal weight value also showing that the TR is being used.
" 153-" - Normal weight value also showing motion is active.
" 142.5" - Normal decimal weight value.
"- 142.5" - Negative decimal weight value.
"$ 142.5" - “Locked On” animal decimal weight value.
" 14-.5" - Normal weight decimal value also showing that the TR is being used.
