D4204-EN Scale Link 2 Technical Manual 39
ZEROUT (D.A.N. 2102) Zero Output
Use this selection to Zero / Balance the weight for the Continuous Serial Gross Weight - Scoreboard Mode setting
#11 & 12 (described above).
ZEROFP (D.AN. 2103) Front Panel Zerout
When enabled, allows the Serial Gross Weight to be Zero/Balanced using Front Panel [Zero] key rather than the
Zero Output selection ZEROUT (D.A.N 2102).
SCRM 2 (D.A.N. 2104) Scoreboard Mode 2
Select scoreboard output number 2
OPSTAT (D.A.N. 2111) Operating Status
The Continuous Operating Status setting in Menu 2 will cause one or more data packets to be transmitted from the
scale continuously.
Refer to the EZII Escape Computer Command Set document D3648 for more information.
-DVADJ (D.A.N. 2199) Dynamic Variable Adjust
When enabled, causes the negative sign to be left justified and numeric values to be right justified.
MENU 2.2 – PORT SETTINGS (JUMP LIST 22)
Computer/Printer Port 1 – Pin 2
C1 BD (D.A.N. 2201) COM 1 Baud Rate
Sets Com 1 baud rate for 1200 – 115200
C1 PAR (D.A.N 2202) COM 1 Parity
Sets Com 1 parity to EVEN, ODD, or NONE
C1DATA (D.A.N 2203) COM 1 Data Bits
Sets Com 1 data bits or 7 or 8
C1 DLY (D.A.N 2204) COM 1 Delay
Com 1 Delay chooses the number of seconds the printer will delay before advancing to the next print line. Select
one of the following:
