D4204-EN Scale Link 2 Technical Manual 47
MENU 4.0 – PRESET, ALARM, & TIMER (JUMP LIST 4)
P MTHD (D.A.N 4001) Pre-Alarm Method
Select WEIGHT OR PERCNT to activate Pre-Alarm
P-ALM (D.A.N. 4002) Pre-Alarm
Enter a value to activate an early warning that scale is reaching the preset weight.
AL OUT (D.A.N. 4003) Alarm Out
TR The Alarm Output allows the alarm capabilities of the preset alarm to be controlled by the TR keys.
The Front Panel Alarm light and the relay output is ON (+12V) when a TR command has been
accepted by the scale.
PRESET Causes the alarm capabilities to be controlled by the preset alarm.
SWITCH Select Alarm Output setting “SWITCH” to illuminate the lamp for an ‘OPEN’ or ‘CLOSED’ condition on
the remote input line or the power cord.
NOTE: SWITCH option will not be present unless
RMINP1 (D.A.N 1401)
or
RMINP2 (D.A.N. 1411)
are set to
SWITCH
BUZZER (D.A.N. 4004) Alarm Buzzer
How long the buzzer sounds can now be modified. It can be set to stay on continuously when alarm is active,
selectable from 1-10 seconds, or OFF.
RELAY (D.A.N. 4005) +12VDC Alarm Output
OFF No 12V signal will be activated
PRESET Standard preset relay, lamp, and alarm functionality. Uses the preset to determine the pulses of the
light, buzzer, and 12V signal.
SETPNT Uses the weight threshold to activate and deactivate the 12V signal
PRTDLY (D.A.N. 4006) Preset Advance Delay
PRTDLY controls the number of seconds to wait before auto-advancing to the next to print the preset, clear the
preset, and clear the “Preset ID” once the target weight has been reached. Enter value in seconds, a value of 0 sets
manual advance.
