D4204-EN Scale Link 2 Technical Manual 45
HIGHWT (D.A.N. 3202) Analog High Weight
For Units with Analog Output
The "HIGHWT "setting allows the user to enter the weight value that equals the high output limit (20mA or 5V) for
the analog output. The “HIGH WT” value must be larger than the “LOW WT” value.
ANAOUT (D.A.N. 3203) Analog Output Option
Analog Output is an optional feature installed on the option board. Jumpers on the option board must match the
setting in this menu.
0-5VDC Analog Output from 0 to 5 Volts DC.
4-20MA Analog Output from 4 to 20mA without error detection
0-20MA Analog Output from 0 to 20mA (error indicated with output below 4mA)
Note: Internal jumpers must also be moved when this selection is changed. Please refer to the Analog Output
Manual (D3708) for further details.
-ANALG
(D.A.N 3204) Negative Analog Output
Allows the analog output 4-20mA setting to represent weight values less than the Analog Low Weight selection
(LOW WT) in Menu 2. This setting allows the signal to represent weights as low as 3mA. This is useful to show
weight values below the Zero/Balance point when the Analog Low Weight selection (LOW WT) is set to 0.
ANTEST
(D.A.N 3209) Analog Output Test
Allows testing of the analog output. Each of the following outputs can be tested: Normal, Minimum, Maximum, and
Saw.
Press SELECT to cycle through available tests.
NOTE: Tests will run continuously until menu item is exited.
MENU 3.3 – ACCELEROMETER (JUMP LIST 33)
Note: Accelerometer must be enabled to use feature. Please contact support for more information.
NOTLVL (D.A.N. 3304) Accelerometer Machine Level
Allows of leveling of accelerometer when installed on machine. Park machine on level ground and level
accelerometer.
ACLFLT (D.A.N. 3305) Accelerometer Filter
Decrease this number to smoothen filtering.
