20 Scale Link 2 Technical Manual D4204-EN
Summed Weight – Total weight of scale A+B+C+D
Scale A – Gross Weight
Scale B – Gross Weight
Scale C – Gross Weight
Scale D – Gross Weight
Mask Number – Mask version that is applied to screen
Software Version – Displays current software version
Hardware Detected – Displays which hardware is recognized by the SL2
9
10
11
12
13
14
15
16
