D4204-EN Scale Link 2 Technical Manual 37
15 Transmit comma delimited data which includes the feeding status 1 time per second.
• Includes Preset, Net Weight, Gross Weight, display unit,(O – Operator, P – PC requested
command), M – Motion, weight tag (GR, M+, etc...), ID, Rotation counter, Date & Time.
• Ends with a <CR>,<LF>.
Output example:
1 2 3 4 5 6
123456789012345678901234567890123456789012345678901234567890123456789
500, 220, 1300,LB,P, ,GR, , 0,18MY15,11:20:19<CR><LF>
27 Transmit comma delimited data which includes the “timer” or “mix counter” 1 time per second.
• Includes Preset, Net Weight, Gross Weight, Ingred/Pen Name, Recipe, Timer/Counter,
Time, Date.
• Ends with a <CR>,<LF>. (Carriage Return, Line Feed).
Output example:
1 2 3 4 5 6
123456789012345678901234567890123456789012345678901234567890
" 200, 130, 340,Ing ,RecNam,00:01:15,10:48A,23MY12"
37 Transmit comma delimited data 1 time every 5 seconds which includes the basic weighing information
for each scale platform, starting "left-to-right" with Scale A, Scale B, Scale C, and Scale D.
• Starts with <STX> (Start of Text).
• Includes Weight displayed, display unit & weight tag (GR, M+, etc...) for each scale.
• The <ETX> (End of Text) control character.
• Checksum Character (C) value that includes all bytes starting after the <STX> up through, but not
including the <ETX> .
• Ends with a <CR> (Carriage Return).
Output example:
Scales A, B, C, & D with scale A selected at the indicator.
^ = STX
@ = ETX
C = Checksum
~ = CR
1 2 3 4 5 6
123456789012345678901234567890123456789012345678901234567890
"^ > 280LB GR, 11300LB NE, 1520LB GR, 2850LB NE@C~"
