DigiTech JAMMAN - Stereo Amp Configurations

22
To rst Amp Input To second Amp Input
To Left (Mono) Input
The Mono Input / Stereo Amp option provides the best stereo imaging for
the Modulation and Pong delay types. Connect the guitar to the JamMan
®
Delay’s LEFT (MONO) Input and connect the LEFT (MONO) and Right outputs to
the inputs of each amp. The DRY OFF button should be OFF for this setup.
Mono Input / Stereo Amp
Making Connections
