Dikai DK-D03S - DRIVE CABLE CONNECTOR

OPERATIONAL MANUAL
D03S THERMAL TRANSFER OVERPRINTER - 19 -
4. Press the Knob to lock the pressure regulator.
3. Drive Cable Connector
A D-Type 44-pin connector, connect with the drive cable.
At no point should the unit be powered until these are securely attached to each unit.
Diagraph 4 Air Pressure Regulator
Φ6mm air inlet
Φ4mm air outlet
Filter
