Dikai DK-D03S - SET VERTICAL OFFSET

OPERATIONAL MANUAL
D03S THERMAL TRANSFER OVERPRINTER - 47 -
4.6.2 Set the Vertical Offset
Note: the machine cannot enter the interface of Advanced Settings and Diagnosis in
RUUNING mode.
1. From the Home Screen (IDLE), click ”Menu”
button to the Menu Screen
3. Enter password”1111”, and press OK to enter
the Advanced settings Screen.
******
4. Press “Vertical” pop up to Digit Keypad.
2. Click “Advance” to pop up a Digit Keypad.
10
5. Enter the number (1 refers to 0.1mm), then
click “OK” button back to Advanced Settings
Screen.
6. Click ”Back” button back to Home Screen.
The Vertical Offset setting is done.
2013-12-15
2013-12-15
Running
Direction
Running
Direction
Print position changes (200 = 20mm)
Print position changes (100 = 10mm)
Shanghai Dikai Coding Industry
