70
www.cndingli.com
S0608 - S0812ACE
P
M
SV2
SV1
S1
S2
L
T
120bar
RV1
IN
SV3
CV1
Pump
Tank
Filter
Function valve
Steer cylinder
Platform loading
(Option)
Lift
cylinder
Lower valve
Sensor
RV1=130bar(JCPT0808AC)
RV1=160bar(JCPT1008AC)
RV1=210bar(JCPT1012AC)
FR1
RV2
Filter
