13
© 2012 Directed� All rights reserved�
Type 4 - PKE + 4x10/5x10
RX: Blue: 1
(-) Ground: Black: 2
(+) 12v: Red: 4
(+) Door Sense Input: White/Purple: 4****
(-) Starter Kill Output: White/Black: 6
(-) Door Sense Input: Blue/White: 10****
(+) Brake Input: Purple/Black: 5
(+) Brake Input
(-) Door Sense Input****
(+) Door Sense Input****
These wires are not required in D2D mode.
6 Green 6 Black
4 Red2 Black 2 Red10 Black
LED
PKE
Prog. Button
Not Used
*
*Sold separately.
**Antenna & Antenna harness are sold with your Remote Starter kit.
***10-feet Antenna Cable is included in the PKE kit.
****Door sense: The polarity of the door sense in the vehicle will determine which wire to connect
from the PKE to the DIRECTED Remote Starter.
Antenna**
Antenna Harness**
D2D Port
Antenna
10-feet Antenna Cable***
D2D Y CABLE
(-) Horn Output: Red/White: 3
Antenna (8 feet)
Antenna (18 feet)
Refer to the
Antenna Location
and Installation Points
section on page 5 for
more information.
4 wires red
connector
3 wires red
connector
(+) Ignition Output
86 85
30
87a
87
(+) Starter Wire
Connect these wires
to the vehicle.
Starter Disable:
This connection is
optional and ad-
ditional parts are
sold separately.
This toggle switch will
bypass the starter disable.
2 White
Optional
Antenna (12 feet)*
(Part# SANT-PKE12)
To Next Page
