Remote pairing
Important:
The antennas must be connected to the PKE module before proceeding to pairing mode.
RF Protocole Selection need to be done prior to pair the PKE to the remote starter. See "Feature Programming" section on
page 20.
Pairing the FOB to the PKE module:
1. Press and release, then press and hold the programming button on the PKE module. The LED will turn on solid indicating
that the PKE module is in pairing mode.
2. Release the programming button.
3. Quickly press and release then press and hold the remote
button.
4. The fob LED will flash red followed by a green flash to confirm the pairing was successful.
5. If more than 1 red LED flash occurs during the programming process, verify antenna connections and repeat the pairing
procedure.
Note: Press and release the programming button at any moment to exit remote pairing mode.
Pairing the PKE system to the remote starter module:
This step is necessary when a remote starter is installed prior to having a PKE system. This allows the remote starter to recog-
nize commands from the PKE system. It is important that the FOB be paired to the PKE module first before proceeding with
this step.
1. Place the remote starter in remote pairing mode (see the remote starter instructions on remote pairing for more informa-
tion).
2. Press and hold the programming button on the PKE. The LED will flash 3 times to confirm that data is being sent to the
remote starter.
3. Release the programming button. The remote starter will confirm the remote learning operation. Refer to the remote starter
installation guide for more information on remote pairing.
Factory reset
To execute a factory reset:
1. Disconnect the power supply from the PKE module.
2. Press and hold the programming button.
3. Reconnect the power supply to the module. The LED will flash 5 times quickly to confirm factory reset.
Diagnostics
LED Parking Lights
Flashing
rate
Event
Flashes x1 Flashes x 1 Slow Lock
Flashes x 2 Flashes x 2 Slow Unlock
Flashes x 3 Flashes x 3 Fast
Enabling PKE through FOB
(Standalone installation only)
Flashes x 3 Flashes x 3 Slow
Remote ID being sent to remote
starter
Flashes x 4 Flashes x 4 Slow PKE learned
Flashes x 5 Flashes x 5 Fast
Disabling PKE through FOB
(Standalone installation only)
Flashes x 5 Flashes x 5 Fast Factory reset
ON continuously N/A
ON con-
tinuously
PKE disabled
