These wires are not required in D2D mode.
6 Green 6 Black
4 Red2 Black 2 Red10 Black
LED
PKE
Prog. Button
CABLE**
TX: Blue: 1
RX: Green: 3
(-) Ground: Black: 2
(+) 12v: Red: 4
*Sold separately.
**DIRECTED SmartStart
TM
cable is sold with your DIRECTED SmartStart
TM
.
***Antenna & Antenna harness are sold with your Remote Starter kit.
****10-feet Antenna Cable is included in the PKE kit.
Note: Door sense: The polarity of the door sense in the vehicle will determine which wire to connect from the PKE to the DIRECTED Remote Starter.
*
(-) Ground: Black: 2
(+) 12v: Red: 4
RX: Blue: 1
LED
D2D Y CABLE
Cut the unused connectors of D2D Y cable and connect
RX (blue), 12v and Ground wires to the corresponding
wires of the D2D cable.
Not Used
RX: Blue
Ground: Black
(+)12v: Red
D2D Port
Antenna***
Antenna Harness***
10-feet Antenna Cable****
Antenna (8 feet)
Antenna (18 feet)
Refer to the
Antenna Location
and Installation Points
section on page 5 for
more information.
DIRECTED
SmartStart
TM
*
3 wires red
connector
(+) Door Sense Input: White/Purple: 4
(Door sense: See note)
(-) Starter Kill Output: White/Black: 6
(-) Door Sense Input: Blue/White: 10
(Door sense: See note)
(+) Brake Input
(-) Door Sense Input (See note)
(+) Brake Input: Purple/Black: 5
(+) Door Sense Input (See note)
(-) Horn Output: Red/White: 3
86 85
30
87a
87
(+) Starter Wire
Connect these wires
to the vehicle.
(+) Ignition Output
Starter Disable:
This connection is
optional and ad-
ditional parts are
sold separately.
This toggle switch will
bypass the starter disable.
Not Used
(+)12v
TX
(-) Ground
RX
2 White
Optional
Antenna (12 feet)*
(Part# SANT-PKE12)
To Next Page
