9
© 2012 Directed� All rights reserved�
Type 2b - PKE + Xpresskit Bypass + Viper/Python/Clifford Directed Remote Starter
(with 6-pin antenna connector)
These wires are not required in D2D mode.
4 Red
(-) Door Status Output
(+) Brake Output
(+) Brake Input: Purple/Black: 5
(-) Starter Kill: White/Black: 6
(-) Door Sense Input: Blue/White: 10****
(+) Brake Input
(+) Ignition Output
(-) Door Sense Input****
Remote
Starter*
4 White
(-) Ground: Black: 2
RX: Blue: 1
(+) 12v: Red: 4
Xpresskit
Interface Module*
(+) Door Sense Input: White/Purple: 4****
(+) Door Sense Input****
D2D Y CABLE
6 Green 6 Black
4 Red2 Black 2 Red10 Black
LED
PKE
Prog. Button
Antenna**
Antenna Harness**
*Sold separately.
**Antenna & Antenna harness are sold with your Remote Starter kit.
***10-foot Antenna Cable is included in the PKE kit.
**** Door sense: The polarity of the door sense in the vehicle will determine which wire to connect
from the PKE to the DIRECTED Remote Starter.
D2D Port
Antenna
10-foot Antenna Cable***
D2D Port
(+) 12v: Red: 4
(-) Ground: Black: 2
RX: Green: 3
TX: Blue: 1
RX: Blue: 1
TX: Green: 3
(-) Ground: Black: 2
(+) 12v: Red: 4
86 85
30
87a
87
(+) Starter Wire
Antenna (8 feet)
Antenna (18 feet)
Refer to the
Antenna Location
and Installation Points
section on page 5 for
more information.
Regular Remote
Start Connections
To The Vehicle
(-) Horn Output: Red/White: 3
4 wires red
connector
4 wires white
connector
3 wires red
connector
Starter Disable:
This connection is
optional and ad-
ditional parts are
sold separately.
This toggle switch will
bypass the starter disable.
Optional
Antenna (12 feet)*
(Part# SANT-PKE12)
2 White
To Next Page
