8
© 2012 Directed� All rights reserved�
Type 2a - PKE + Xpresskit Bypass + AutoStart or AstroStart or Viper/Python/Clifford
Directed Remote Starter (with 4-pin antenna connector)
Note: 8210 Antenna Universal Adapter is required and sold separately.
These wires are not required in D2D mode.
4 Red
(-) Door Status Output
(+) Brake Output
(+) Brake Input: Purple/Black: 5
(-) Starter Kill: White/Black: 6
(-) Door Sense Input: Blue/White: 10***
(+) Brake Input
(-) Door Sense Input***
Remote
Starter*
8210 Main
Universal
Adaptor*:
Refer to the
8210 guide.
Regular Remote
Start Connections
To The Vehicle
4 White
(+) 12v: Red: 4
(-) Ground: Black: 2
RX: Green: 3
TX: Blue: 1
RX: Blue: 1
TX: Green: 3
(-) Ground: Black: 2
(+) 12v: Red: 4
(-) Ground: Black: 2
RX: Blue: 1
(+) 12v: Red: 4
Xpresskit
Interface Module*
D2D Y CABLE
6 Green 6 Black
4 Red2 Black 2 Red10 Black
LED
PKE
Prog. Button
Antenna**
8210*
Antenna Harness**
8210*
*Sold separately.
**Antenna & Antenna harness are sold with your Remote Starter kit.
*** Door sense: The polarity of the door sense in the vehicle will determine which wire to connect
from the PKE to the DIRECTED Remote Starter.
D2D Port
Antenna
D2D Port
(-) Horn Output: Red/White: 3
Antenna (8 feet)
Antenna (18 feet)
Refer to the
Antenna Location
and Installation Points
section on page 5 for
more information.
(+) Ignition Output
86 85
30
87a
87
(+) Starter Wire
4 wires red
connector
4 wires white
connector
3 wires red
connector
Starter Disable:
This connection is
optional and ad-
ditional parts are
sold separately.
This toggle switch will
bypass the starter disable.
(+) Door Sense Input: White/Purple: 4***
(+) Door Sense Input***
2 White
Optional
Antenna (12 feet)*
(Part# SANT-PKE12)
To Next Page
