12
© 2012 Directed� All rights reserved�
Type 3c - PKE + Xpresskit Bypass + DIRECTED SmartStart + Viper/Python/Clifford
Directed Remote Starter (with 4-pin antenna connector)
Note: 8210 Antenna Universal Adapter is required and sold separately.
(+) Door Sense Input: White/Purple: 4****
(-) Starter Kill Output: White/Black: 6
(-) Door Sense Input: Blue/White: 10****
(+) Brake Input: Purple/Black: 5
(+) Brake
(-) Door Sense****
(+) Door Sense****
Antenna
RF Port
ESP Red
Connector
ESP Black
Connector
6 Green 6 Black
4 Red
2 Black
2 Red10 Black
LED
PKE
Prog. Button
(-) Ground: Black: 2
(+) 12v: Red: 4
LED
(+)12v
TX
(-) Ground
RX
D2D Y CABLE
*Sold separately.
**Antenna, Antenna harness & DIRECTED SmartStart
TM
cable are sold with your Remote Starter kit.
***10-foot Antenna Cable is included in the PKE kit.
**** Door sense: The polarity of the door sense in the vehicle will determine which wire to connect
from the PKE to the DIRECTED Remote Starter.
(-) Horn Output: Red/White: 3
Antenna (8 feet)
Antenna (18 feet)
Refer to the
Antenna Location
and Installation Points
section on page 5 for
more information.
DIRECTED
SmartStart
TM
*
3 wires red
connector
(+) Ignition Output
86 85
30
87a
87
(+) Starter Wire
Not Used
Starter Disable:
This connection is
optional and ad-
ditional parts are
sold separately.
The remote starter model will
determine which connector to use.
Refer to the DIRECTED SmartStart
install guide for proper connection.
OR
This toggle switch will
bypass the starter disable.
D2D Red
Connector
4 White
Xpresskit
Interface Module*
(+) 12v: Red: 4
(-) Ground: Black: 2
RX: Green: 3
TX: Blue: 1
Connect these wires
to the vehicle.
8210 Main
Universal
Adaptor*: Refer
to the 8210 guide.
Antenna**
8210*
Antenna Harness**
8210*
CABLE**
2 White
Optional
Antenna (12 feet)*
(Part# SANT-PKE12)
To Next Page
