Directed DS4 Plus User Manual

28
DS4+ VW10
© 2017-11-02 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Volkswagen Jetta 2006-2010
12V Red/Black or Red/Yellow 1 (+) VESCM connector L, under drivers dash. Black 2 A
Parking Light Gray/Yellow 3 (+) Headlight switch. Black 10 B
Parking Light Interrupt Red/White 8 Cut Headlight switch. Black 10 B
Starter Red/Black or Red/Brown 1 (+) VESCM connector G, under drivers dash. Black 12 C
Ignition Black or Black/Green 11 (+) VESCM connector G, under drivers dash. Black 12 C
FT CAN High Orange/Green 8 Data VESCM connector G, under drivers dash. Black 12 C
FT CAN Low Orange/Brown 7 Data VESCM connector G, under drivers dash. Black 12 C
HS CAN High Orange/Black 6 Data OBDII. Black 16 D
HS CAN Low Orange/Brown 14 Data OBDII. Black 16 D
Volkswagen Jetta SportWagen 2009
12V Red/Black 1 (+) VESCM connector L, under drivers dash. Black 2 A
Parking Light Gray/Yellow 3 (+) Headlight switch. Black 10 B
Parking Light Interrupt Red/White 8 Cut Headlight switch. Black 10 B
Starter Red/Black or Red/Brown 1 (+) VESCM connector G, under drivers dash. Black 12 C
Ignition Black 11 (+) VESCM connector G, under drivers dash. Black 12 C
FT CAN High Orange/Green 8 Data VESCM connector G, under drivers dash. Black 12 C
FT CAN Low Orange/Brown 7 Data VESCM connector G, under drivers dash. Black 12 C
HS CAN High Orange/Black 6 Data OBDII. Black 16 D
HS CAN Low Orange/Brown 14 Data OBDII. Black 16 D
Volkswagen Rabbit 2006-2009
12V Red/Black or Red/Yellow 1 (+) VESCM connector L, under drivers dash. Black 2 A
Parking Light Gray/Yellow 3 (+) Headlight switch. Black 10 B
Parking Light Interrupt Red/White 8 Cut Headlight switch. Black 10 B
Starter Red/Black or Red/Brown 1 (+) VESCM connector G, under drivers dash. Black 12 C
Ignition Black or Black/Green 11 (+) VESCM connector G, under drivers dash. Black 12 C
FT CAN High Orange/Green 8 Data VESCM connector G, under drivers dash. Black 12 C
FT CAN Low Orange/Brown 7 Data VESCM connector G, under drivers dash. Black 12 C
HS CAN High Orange/Black 6 Data OBDII. Black 16 D
HS CAN Low Orange/Brown 14 Data OBDII. Black 16 D
