Dish Network Dish ViP722K - Satellite Receiver Front Panel; Satellite Receiver Back Panel

Satellite Receiver
21
Satellite Receiver Front Panel
SATELLITE RECEIVER FRONT PANEL
SATELLITE RECEIVER BACK PANEL
Note: Your receiver may look slightly different than the unit shown above.
Satellite In
Connection to
your satellite dish
YPbPr/Component
Output
Optional connection to
your high-definition
TV video input
Remote
Antenna
Connection to
remote control
antenna
Audio/Video
Output
High-quality standard-
definition connection
to your TV audio
and video input
Ethernet Port
Connect to
your broadband
home network
USB Port
Connect to
multimedia
devices
Phone Jack
Connect to your
telephone line
HDMI
Output
Provides digital
audio and video
to your HDTV
Digital Audio
Output connection
to a high-quality
digital sound
decoding system
Home
Distribution
In-home
distribution
output
Module Port
Connection to the
optional module
(sold separately)
Note: Your receiver may look slightly different than the unit shown above.
