C16x/C24x/C30x Operator’s Manual Service - 99
As Needed
As Needed
Replace In-Line Fuel Filter
See engine service manual for procedure.
Adjust Wheel Track Tension
Adjust wheel track tension on both sides when
tracks are replaced.
To adjust:
1. Park machine on level and firm ground.
2. Lay straight edge on top of track, spanning
from sprocket to front idler roller.
3. Tighten bolt (2):
• Loosen jam nut (1).
• Turn bolt (2) counterclockwise until
distance between track and straight edge
is 1/4” (6 mm).
• Tighten jam nut (1).
To test:
Drive forward one track length and check tension
with straight edge:
• If tension is too loose, tighten bolt (2).
• If tension is too tight, loosen bolt (2).
Location Task Notes
Engine Replace in-line fuel filter
Adjust wheel track tension
Check battery
To Next Page
