C16x/C24x/C30x Operator’s Manual Systems and Equipment - 75
Optional Equipment
Backfill Blade
The optional backfill blade must be in position
related to the job at hand.
Stowed position
Install the backfill blade in stowed position for
transport and drilling.
1. Shut down engine.
2. Insert backfill blade in upright position onto
mounting stub (2).
3. Secure with pin (1).
Work position
Install the backfill blade in work position for
backfilling only.
1. Shut down engine.
2. Insert backfill blade in work position onto
mounting stub (2).
3. Secure with pin (1).
Drilling Attachment
The optional Roto Witch
®
drilling attachment
can be used to drill under obstructions such as
sidewalks and driveways. For operational
information, see “Drill” on page 57.
IMPORTANT: Completely remove backfill
blade for trenching.
