C16x/C24x/C30x Operator’s Manual Overview - 5
Operator Orientation
Operator Orientation
1. Front of unit
2. Right side of unit
3. Rear of unit
4. Left side of unit
Operating Area
The operating area (A) is at the rear of the
machine, behind the control console.
Any other area less than 6 ft (2 m) from the
machine is a danger area (B). Stay away.
Moving digging teeth can kill. Trench cave-in can cause
you to fall. Stay away.
To help avoid injury:
• Keep everyone from danger area (B) during operation.
• If someone enters danger area (B) during operation, use emergency shutdown.
6ft/2m
