Specifications - 108 C16x/C24x/C30x Operator’s Manual
C16x
Power Train U.S. Metric
Hydraulic ground drive: infinitely variable from zero to maximum, speed and direction controlled with dual
levers
Digging chain drive: hydraulic direct drive, lever-operated, one speed forward and reverse
Trencher drive: hydraulic direct drive
Pump drive: direct drive from engine
Spoils handling drive: mechanical, attached to and rotates with headshaft
Track
Width 200 mm 200 mm
Ground pressure 4.5 psi 31 kPa
Hydraulic System U.S. Metric
Dual pump total capacity @ 3600 rpm 11.5 gpm 43.5 L/min
Pump characteristics @ 3600 rpm to ground drive:
Pressure, relief valve setting 2200 psi 152 bar
Capacity 1.5 gpm 5.7 L/min
Pump characteristics @ 3600 rpm to digging drive:
Pressure, relief valve setting 3500 psi 241 bar
Capacity 10 gpm 37.9 L/min
Fluid Capacities U.S. Metric
Hydraulic reservoir 11 gal 41.6 L
Hydraulic system 11.5 gal 43.5 L
Fuel tank 2.3 gal 6.5 L
Engine oil 47 oz 1.47 L
Noise Levels
Operator ear 87 dBA sound pressure per ISO 6394
Exterior 97 dBA sound power per ISO 6393
Vibration Levels
Vibration at the operator’s hand during normal operation is less than 2.5 m/s
2
