C16x/C24x/C30x Operator’s Manual Specifications - 107
C16x
General
Ditch Witch
®
model C16x, self-propelled, hydraulic, pedestrian, skid steered, track drive, rigid frame, chain
type trencher.
Operational U.S. Metric
Vehicle speeds
Maximum transit forward 120 fpm 36.6 m/min
Maximum transit reverse 120 fpm 36.6 m/min
Digging chain speed
19K 366 fpm 111.6 m/min
35K 309 fpm 94.2 m/min
Spoils handling (single, open-end auger):
Outer diameter 17 in 432 mm
Maximum operating weight 1895 lb 860 kg
Power U.S. Metric
Engine: Briggs & Stratton
®
Vanguard
TM
16.0 Small Block V-Twin Horizontal Shaft
Fuel: gasoline
Cooling medium: air
Number of cylinders: two
Displacement
29.23 in
3
479 cm
3
Bore 2.68 in 68 mm
Stroke 2.60 in 66 mm
Manufacturer’s net power rating @ 3600 rpm (SAE J1940) 16 hp 11.9 kW
Rated speed 3600 rpm 3600 rpm
Fuel consumption 1.33 gph 5 L/h
Maximum tilt angle* 20° 20°
*Exceeding these operational angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
Battery
310 CA, 12V, reserve capacity 30 min
