Systems and Equipment - 74 C16x/C24x/C30x Operator’s Manual
Optional Equipment
Optional Equipment
See your Ditch Witch
®
dealer for more information about the following optional equipment.
NOTICE: Adding or removing optional equipment changes counterweight requirement. Use applicable
chart on page 77 or page 78 to ensure you have the correct counterweights for your configuration.
Equipment Description
booms provide depth options of 18” (457mm), 24” (610 mm), 30” (760 mm), 36”
(915 mm) or 48” (1220 mm); each length is available with an adjustment
screw for tensioning the digging chain
mechanical trench cleaner removes spoils from the trench floor
backfill blade cover trench using machine
drilling attachment drill under sidewalks and driveways
counterweights provide unit balance in various configurations
10-tooth sprocket slows digging chain speed to allow teeth time to penetrate into the ground
and increase performance in rocky or extremely hard soil
