Specifications - 110 C16x/C24x/C30x Operator’s Manual
C24x
General
Ditch Witch
®
model C24x, self-propelled, hydraulic, pedestrian, skid steered, track drive, rigid frame, chain
type trencher.
Operational U.S. Metric
Vehicle speeds:
Maximum transit forward 176 fpm 53.6 m/min
Maximum transit reverse 136 fpm 41.5 m/min
Digging chain speed:
19K 366 fpm 111.6 m/min
35K 309 fpm 94.2 m/min
Spoils handling (single, open-end auger):
Outer diameter 17 in 432 mm
Maximum operating weight 1915 lb 869 kg
Power U.S. Metric
Engine: Honda
®
GX690
Fuel: gasoline
Cooling medium: air
Number of cylinders: two
Displacement
42 in
3
688 cm
3
Bore 3.07 in 78 mm
Stroke 2.83 in 72 mm
Manufacturer’s net power rating @ 3600 rpm (SAE J1349) 22.1 hp 16.5 kW
Rated speed 3600 rpm 3600 rpm
Fuel consumption @ 3600 rpm 1.77 gph 6.7 L/h
Maximum tilt angle* 20° 20°
*Exceeding these operational angles will cause engine damage. This DOES NOT IMPLY machine is stable
to maximum angle of safe engine operation.
Battery
310 CA, 12V, reserve capacity 30 min
