JT5 Operator’s Manual Systems and Equipment - 107
Quick Wrench
CMW
®
Quick Wrench
To attach or remove downhole tools, use quick wrench to join or break the joint.
Attach quick wrench in either the join or break position.
• Unbolt vise (1) and place jaws around pipe.
• Bolt jaws of vise together.
• Place jaw (2) around pipe.
• Pin handles (3) to wrench jaws. Be sure handles are both up.
• Attach pivot nuts (4) to wrench handles so that screw drive handle (5) is over joint.
Moving tools will kill or injure. Never use pipe wrenches
on drill string.
IMPORTANT: Apply TJC to threads and hand-tighten joint before attaching quick wrench components to
tighten joint.
Join Break
