Controls - 22 JT5 Operator’s Manual
Set-up Console
CMW
®
Set-up Console
1. Engine stop button
2. Stabilizer and frame tilt control
3. Left track control
4. Right track control
Item Description Notes
1. Engine stop button To stop engine, press. IMPORTANT:
• If this switch is used to stop
drilling unit, turn ignition switch off
if machine will be left unattended
for long periods of time. Battery
discharge can occur.
• If wrenches are engaged when
engine stop button is pressed,
wrenches will remain engaged but
could gradually open.
