Complete the Job - 116 JT5 Operator’s Manual
Rinse Equipment
CMW
®
Rinse Equipment
Using Optional Washwand
Connect the washwand at quick connect at rear
of unit. Close valve (shown) to shut off flow to
spindle.
Spray water onto equipment to remove dirt and mud. Some pressure might be needed to remove dried
mud from wrench area.
IMPORTANT:
• Never use high flow when using wash
wand.
• Use extreme caution when working with
highly pressurized water.
Read operator’s manual. Know how to use all controls.
Your safety is at stake. 273-475
To help avoid injury: Failure to prime the drilling fluid pump will cause
flow fluctuations, which will make it difficult to control the washwand. For
instructions, see “Connect Fluid System” on page 69.
Pressurized fluid or air could pierce skin and cause
severe injury. Refer to operator’s manual for proper use. 270-6035
NOTICE: Do not spray water onto operator’s console. Electrical components could be damaged. Wipe
down instead.
