JT5 Operator’s Manual Systems and Equipment - 91
Electric Strike System
CMW
®
ESID Diagnostic Codes
When strike system detects a problem, an error code will be displayed. Anytime this happens, press self
test button to retest. If error code is still displayed and does not appear in this chart, have control module
checked or replaced.
Code Display Condition Result
502 2.5V REF 2.5V reference error in ESID internal reference failure, ESID may not
give valid readings
503 -5V REF -5V reference error in ESID internal reference failure, ESID may not
give valid readings
504 CLK RESP clock response error clock may not be working
505 LCD RESP LCD response error LCD display may not work
506 LED RESP LED response error LED display may not work
507 LCD CONTR LCD contrast error LCD contrast not saved properly
508 COP RESET cop watchdog error processor has reset, unknown status of
ESID code
510 STRB DVR strobe driver output error strobe may not function
511 HORN DVR horn driver output error horn may not function
512 BAT POWER battery power/horn driver
error
strike hold on power may not function
513 TEST WIRE no continuity on test wire for
testing ESID
Information Center may not be able to
reset ESID
515 STR VOLT strike voltage input error
516 STR COIL strike current input error
517 POST AC V self test ac voltage input
error
self test of ac voltage stake failed
518 POST AC I self test ac current input
error
self test of ac current coil failed
519 POST DC V self test dc voltage input
error
self test of dc voltage input amplifier
failed
520 POST DC I self test dc current input
error
self test of dc current input amplifier
failed
521 V NOT GND strike voltage input stake not
grounded
self test of voltage stake failed
588 EEP WRITE EEProm write error ESID may not be able to record strike
history
589 MISC CODE invalid error report entry software error report
