JT5 Operator’s Manual Service - 133
100 Hour
CMW
®
100 Hour
Drilling Unit
Change Fuel Filters
Change canister fuel filter (top) and inline fuel
filter (bottom) every 100 hours.
1. Remove filter.
2. Fill new filter with clean fuel.
3. Apply fuel oil over the gasket and hand-
tighten.
Location Task Notes
DRILLING
UNIT
Change fuel filters
Check fan belt tension
IMPORTANT: The canister fuel filter is located
behind the engine oil filter.
