JT5 Operator’s Manual Controls - 33
Engine Compartment
CMW
®
2. DrillLok™/tracker
control key
To allow tracker operator to
stop thrust and rotation, move
key to enable position (up).
To override DrillLok/tracker
control mode, move key to
override position (right).
IMPORTANT: Remove key and keep
in tracker operator’s possession.
3. Battery disconnect
switch
To connect, turn clockwise.
To disconnect, turn
counterclockwise.
Item Description Notes
c00ic122w.eps
