Plow - 108
RT45 Operator
’s Manual
Setup
Feed Product
1.
Remove c
able guid
e.
2.
Feed cable thro
ugh tube from top to
bottom.
3.
Replace cable guide and tighten
fasteners.
4.
Secure cable.
Prep
are T
ractor
1.
Fasten and adjust seat belt.
2.
S
tart tractor
.
3.
Adjust to low throttle.
4.
Release parking br
ake.
5.
Move gr
ound driv
e control
to low
.
6.
Raise backfill blad
e, if equipped.
NOTICE:
Use on
ly genuine Ditch Witch
®
cable guide.
108
