Controls - 58
R
T45 Operator
’s Manual
Seat
Seat
1.
Seat belt
2.
Seat slide cont
rol
Item
Description
Notes
1.
Seat bel
t
T
o fasten,
inse
rt latch into
buckle. Adjust until seat belt
is low and tight.
T
o release,
lift top of buckle.
2.
Seat slide control
T
o slid
e seat forw
ard or
backward, pull or push left,
then adjust seat.
T
o lock seat in place, release.
58
