RT45 Operator’s Manual Specifications - 193
A323 Backhoe
*Lift capacities are for a stationary machine supported by stabilizers.
R Stabilizer spread, operating 104 in 2.6 m
U Leveling angle 10° 10°
General U.S. Metric
Bucket
Width 12 in 305 mm
Capacity
1.1 ft
3
0.03 m
3
Backhoe weight with bucket 1125 lb 511 kg
Lift capacity, boom over end and swing arc, SAE*
@ 48” (1.2 m) 957 lb 434 kg
@ ground level 1044 lb 474 kg
@72” (1.8 m) 783 lb 355 kg
Lift capacity, dipperstick over end and swing arc, SAE*
@48” (1.2 m) 1784 lb 809 kg
@72” (1.8 m) 1500 lb 681 kg
Swing arc 160° 160°
Digging force
Using bucket cylinder 5340 lb 23.8 kN
Using dipperstick cylinder 4050 lb 18 kN
