Specifications - 192 RT45 Operator’s Manual
A323 Backhoe
A323 Backhoe
Dimensions U.S. Metric
A Transport height 80.5 in 2.0 m
C Ground clearance 23 in 584 mm
D Backhoe length, stowed 60 in 1.5 m
F Digging depth, maximum 72 in 1.8 m
G Digging depth, 2’ (0.6 m) flat bottom 66 in 1.7 m
J Operating height, fully raised 97 in 2.5 m
K Loading height 46 in 1.2 m
L Loading reach 55 in 1.4 m
M Reach from swing pivot 102 in 2.6 m
N Swing pivot to centerline axle 32 in 813 mm
P Bucket rotation 132° 132°
B Stabilizer spread, transport 64 in 1.6 m
E Backhoe or basic unit width 57 in 1.5 m
