Drill - 120 RT45 Operator’s Manual
Operate
Remove Rod
If the length of rod outside the bore reaches 30’ (9 m), ask a helper to remove rod sections as needed.
Remove Rod Section
1. Operate controls to stop rotation of drilling attachment.
2. Shut down engine.
3. Disconnect and remove applicable rod section with applicable special tool (p/n 351-272). See
“Disassemble Drill String” on page 122.
Rotating shaft will cause death or serious injury. Stay
away.
To help avoid injury:
• Only access drill string with hands when engine is shut down.
• Always remove second rod (as shown). Leave first rod section attached to drilling attachment.
t48om060w.eps
To Next Page
