RT45 Operator’s Manual Specifications - 189
RT45 Tractor with H313 Trencher
Backfill Blade U.S. Metric
Blade width 64 in 1.6 m
Blade height 14 in 355 mm
Lift height above ground 12 in 300 mm
Blade drop below ground 8 in 200 mm
Maximum swing angle (left/right) 28° 28°
Tilt angle (up/down) 11° 11°
Power U.S. Metric
Engine: Deutz
®
D2.9L4, diesel, EPA Tier 4, EU stage IIIa
Cooling medium: water
Injection: direct
Aspiration: natural
Number of cylinders: 4
Displacement
177 in
3
2.9 L
Bore 3.6 in 92 mm
Stroke 4.3 in 110 mm
Engine manufacturer’s gross power rating (SAE J1995) 48.8 hp 36.4 kW
Estimated net power rating (SAE J1349) 46 hp 34 kW
Rated speed 2600 rpm 2600 rpm
Maximum engine tilt angles*
Longitudinal 30° 30°
Lateral 30° 30°
*Exceeding these operating angles will cause engine damage. This DOES NOT IMPLY machine is
stable to maximum angle of safe engine operation.
