R
T45 Operator
’s
Manual
Safety - 27
Attachment Safety Alerts
R
WIII/RWIV
5
Moving digging teeth will cause serious injury or
death. S
tay away
.
275-443
6
Hot part
s may cause burns. Do not touch until coo
l
or wear gloves.
275-355
7
Fall possible. Riders can fa
ll from machine and be
injured or killed. Only
operator is allowed on machine.
273-487
1
T
urning shaft will kill you or crush arm or leg. S
tay
away
.
275-197
27
29
