R
T45 Operator
’s
Manual
Controls - 47
Right Fender
2.
Plow lift control
T
o raise, pull.
T
o lower
, push.
3.
Backfi
ll blad
e tilt/plow
swing selector
T
o control backfill blade tilt,
push.
T
o control plow swing, pull.
Use when optional 6-way backfill
blade is installed.
Item
Description
Notes
c00ic204h.eps
c00ic264h.eps
47
49
