DITEC DOD - Ditec DOD14 Axle Installation

10
IP2395EN
4. Ditec DOD14 axle installation
WARNING: For correct operation we advise to move the door at a speed lower than 0.2 m/s.
DOD14
LCA85
LCA85B
FLM
FL24
AXK4
AXK5M
AXK5I
AXK5NM
AXK5NI
AXR7
SOFAP20
SOF2M20-SOF3M20
SOFA15-SOFA20-SOFA25
Ø
N
DOD14
Type Pinion Crown
Reduction
ratio
Torque
[Nm]
Rotating
speed
[RPM]
Door cable
pulley
[Ø mm]
Door
speed
[m/s]
Max Run
[m]
Max force
[N]
DOD 14 - - 1:1 60 22
102
124
158
226
Ø
0,12
0,14
0,18
0,26
=Ø:868
8,7
10,6
13,6
19,4
=Ø:11,66
1176
968
759
531
=120000:Ø
