DITEC DOD - Ditec DOD14 PS Electrical Connections

20
IP2395EN
10 m (4G x 1,5 mm²)
1,5 m (3G x 1,5 mm²)
12 11
LN
W
V
W
U
A
C
M
1~
-
~
~
+
B
Black
Brown
Grey
or
Blue
Brake
com
Yellow/Green
12
11
12B
11B
Opening limit switch
Additional switch
Closing limit switch
With the provided push button the control panel isn’t necessary, the automation works as “hold
to run” function.
9.4 Ditec DOD14PS electrical connections
230 V~ - 50 / 60 Hz
Power supply
