DITEC DOD - Technical Data; Application

7
IP2395EN
1. Technical data
1.1 Application
Service class: 4 (minimum 100 cycles a day for 10 years or 200 cycles a day for 5 years)
Use: INTENSIVE (For pedestrian accesses with intensive use).
- The operating performance specifications refer to the recommended weight (about 2/3 of maxi-
mum allowed weight). Use with maximum allowed weight could reduce the above performance
specifications in tecnhical data.
- The service class, operating times and number of consecutive cycles are merely approximate.
These have been statistically determined in average conditions of use and are not certain for
each single case.
- Each automatic entrance features variable factors such as: friction, balancing and environ-
mental conditions that can substantially change both the duration and operating quality of
the automatic entrance or part of its components (including automatic system). It is up to the
installer to adopt adequate safety coefficients for each single installation.
The given operating and performance features can only be guaranteed with the use of
DITEC accessories and safety devices.
ATTENTION: DOD14 geared motors may be used for operating sectional doors only if
correctly balanced.
The sectional doors can only be manually moved by means of a handle (installing the
DODSBV release device) or a chain (installing the DODSBC release device).
Ditec DOD14 Ditec DOITDD1P
Ditec
DOD14PS
Power supply 230 V~ 50 / 60 Hz
Absorption 3 A
Motor power 350 W
Torque 60 Nm
Holding torque 300 Nm
Revolution
transmission shaft
22 rpm
RPM controlled by limit switch 27.5
Capacitor 22 μf
Service class 4 - INTENSIVE
Continuous operating time (S2) 30 min
Intermittence (S3) 50%
Temperature
( with NIO enable)
-20°C +55°C -35°C +55°C -20°C +55°C
Degree of protection IP40
Weight 15 kg
Control panel LCA85 LCA85B -
