DITEC DOD - Machinery Directive; Dimensions

8
IP2395EN
2. Dimensions
225
90
135
120
40
40
60
100
100
5
65
65
264
135
30
320
40
Ø25.4 (1")
6.35 (1/4")
6.35
(1/4")
9.5
(3/8")
NOTE: Unless otherwise specified, all measurements are in mm.
1.2 Machinery Directive
According to the Machinery Directive (2006/42/EC), the installer who motorises a door or gate has
the same obligations as the manufacturer of a machine, and as such must:
- prepare the technical documentation, which must contain the documents indicated in Annex V
of the Machinery Directive;
(the technical documentation must be kept and made available to the competent national
authority for at least ten years, starting from the date of construction of the motorised door);
- draw up the EC statement of conformity according to Annex II-A of the Machinery Directive and
hand it over to the customer;
- affix the CE marking to the motorised door in accordance with point 1.7.3 of Annex I of the
Machinery Directive.
