revision: 1
FlexxPump 125 B
User Manual
12
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
3.4 Technical data
Housing
Dimensions without cartridge width x height x
depth
83 x 82 x 85
mm
Dimensions with catridge 83 x 152 x 85
Weight (without cartridge) appx. 350 g
Mounting options backside: female thread M5 (2x)
bottom: female thread M5 (1x)
bottom: male thread M16 (1x)
max. torque mounting 3 Nm
Mounting position upright
Material housing PA 6.6 GF30 / POM
Material outlet stainless steel
Operating temperature -10 ... +60 °C
Lubricant and hydraulic
Volume cartridge 125 ml
Lubricant characteristics grease until NLGI class 2
Number of outlets 1
Hydraulic connection directly or via PA-tube
Number of lubrication points 1
max. pressure 35 bar
Grease delivery per stroke 0.16 (-5%) cm³
Electrics
Display LCD
Operating voltage 4.5 V
Protection - A
Protection class IP 54
