5.3 Commissioning
Mount the FlexxPump 125 B carefully according to the steps described in chapter 5.2.
Depending on the scope of delivery, you must also carry out the following additional
measures for the rst-time commissioning:
1. Mechanical fastening
Fix the FlexxPump 125 B mechanically through the M5 female threads or through the
M16 male thread of the FlexxPump 125 B lubricant outlet. Pay particular attention to
the maximum tightening torques permissible for the M5 female threads!
2. Check the assembly
Make sure that the FlexxPump 125 B is properly and completely assembled. In
particular, the battery must be inserted and a lubricant cartridge must be tted.
3. Power on
If you want to put the FlexxPump 125 B into operation, switch on the FlexxPump 125
B. Only if you switch on the FlexxPump 125 B, it delivers lubricant to the lubrication
point according to the settings. The detailed description for powering on can be found
in chapter 6.3.3.
4. Execute FIL function
Execute the FIL function. The detailed description can be found in chapter 6.3.10.
FlexxPump 125 B performs a certain number of strokes and transports the lubricant
from the cartridge to the outlet.
5. Hydraulic connection
Connect the consumer hydraulically to the FlexxPump 125 B. If you connect tubes to
the FlexxPump 125 B, make sure that the tubes and connectors are installed tightly,
cleanly and correctly.
 Ideally, use tubes prefilled with the appropriate lubricant!
6. Check the settings on FlexxPump 125 B
Check the factory settings of FlexxPump 125 B with the required values for the
lubrication point and adjust them if necessary. The factory settings are recorded
in chapter 6.2; changes at the FlexxPump 125 B must be made in the SET-Menu,
chapter. 6.3.6, and in the PRO-Menu, chapter 6.3.8 to 6.3.9.
