FlexxPump 125 B
User Manual
25
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
Display in LCD Meaning Chapter
dark Battery not connected; battery completely discharged 6.3.3
OFF FlexxPump 125 B is switched off 6.3.3
On FlexxPump 125 B is ready for operation; FlexxPump
125 B dispenses lubricant in accordance to the
operating mode and the set values
6.3.3
Errors
E1 Error E1 (Empty cartridge / Cartridge error) 6.4
E2 Error E2 (Overload) 6.4
E3 Error E3 (Undervoltage, battery empty) 6.4
E4 Error E4 (serious mistake) 6.4
Sub-Menu
INF INF-Menu 6.3.4
/
6.3.5
b01 Firmware version of the FlexxPump 125 B
h06 Currently set value of the dispensing time h
c01 Currently set value of the number of strokes c
6 Currently set value of the emptying time Et
SET SET-Menu 6.3.6
-h- Operating mode Hour-Mode
Et Operating mode Empty-Time-Mode
RUN RUN-Menu 6.3.7
01...35 During the manually triggered active RUN command
("Quick-Check"/special donation), the LCD displays the
approximate back pressure in bar. In addition, the green
LED lights up.
PRO PRO-Menu 6.3.8
/
6.3.9
h1...99 Adjustable setting of the dispensing time h
c1...10 Adjustbale setting of the number of strokes c
1...24 Adjustabe setting of the emptying time Et
FIL FIL-Menu 6.3.10
01...35 During the manually triggered active FIL command, the
LCD displays the approximate back pressure in bar. In
addition, the green LED lights up.
Clr If the process is aborted during the FIL command, Clr
appears rst.
