DMP Electronics XR Series User Manual

Digital Monitoring Products, Inc. | Troubleshooting Guide 7
OUTPUT INFORMATION
1
Dry Contact Relays DMP Part #305�
2
Single pole, Double throw�
3
Rated at 1 Amp @ 30 VDC resistive�
4
May be activated by any of the following:
Zone Condition (Open/Short) Output Schedule Manually from User Menu
Communication Fail Armed Area Annunciation Fire Alarm / Fire Trouble
Other System Conditions
ANNUNCIATOR OUTPUTS
Available on XT30/XT50 Series, XR150/XR550 Series, CellComLTE-V, iComSL, Dualcom, and 716 Output Expander�
1
Switch to GROUND when activated�
2
Do not provide voltage�
3
50mA resistive�
4
Activated by same conditions as Model 305 Dry Contact Relay and Voltage outputs�
PANEL OUTPUT NUMBER
XR150/XR550 Series 3-6
XT30/XT50 Series 1-4
