34 Digital Monitoring Products, Inc. | Troubleshooting Guide
DISARMING/ARMING & LATE TO CLOSE
Disarming and Arming messages should include a 2-digit area number - AA and three digit user number - ZZZ in
addition to the 3-digit event code listed below� The Qualifier should be 1 for Disarming and 3 for Arming� The Late to
Close message should include the area number - AA if area schedules are used� If area schedules are not used then the
area number should be 00� The user number for Late to Close should be 000� The Qualifier should be 1�
DMP PANEL MESSAGE
SERIAL 3 PROTOCOL CONTACT ID
EVENT DEFINITION SUB-MESSAGE CID CODE DEFINITION
DISARMING Q OP 402 OPENING - Group - User ZZZ
ARMING Q CL 402 CLOSING - Group - User ZZZ
DMP PANEL MESSAGE
SERIAL 3 PROTOCOL CONTACT ID
SYSTEM MESSAGE CID CODE DEFINITION
LATE TO CLOSE 06 454 TROUBLE - Failed to Close
DOOR ACCESS
Door Access messages should include a 2-digit keypad number - AA and three digit user number - ZZZ in addition to
the 3-digit event code listed below� The Qualifier should be 1�
DMP PANEL MESSAGE
SERIAL 3 PROTOCOL CONTACT ID
EVENT DEFINITION SUB-MESSAGE CID CODE DEFINITION
DOOR ACCESS J DA 422 ACCESS - Access Gained - User ZZZ
OPENING/CLOSING SCHEDULE CHANGES
Opening/Closing Schedule Changes should include a 2-digit area number - AA and three digit user number - ZZZ in
addition to the 3-digit event code listed below� If area schedules are not being used the area number should be 00� The
Qualifier should be 1�
DMP PANEL MESSAGE
SERIAL 3 PROTOCOL CONTACT ID
EVENT DEFINITION SUB-MESSAGE CID CODE DEFINITION
SCHEDULE CHANGE 1 PE
1
630 TROUBLE - Schedule Changed
1
PE = Permanent
TE = Temporary
PR = Primary
SE = Secondary
S1 = Shift 1
S2 = Shift 2
S3 = Shift 3
S4 = Shift 4
