Digital Monitoring Products, Inc. | Troubleshooting Guide 33
DMP SENDING CONTACT ID:
EVENT DEFINITIONS
IN THE CID FORMAT:
FIELDS 1-4 Account Number
FIELD 5-6 Indicate that a message is in CID format
FIELD 7 Event Quantifier:
1 (New Event)
3 (New Restoral or Closing)
6 (Previously reported condition still present)
FIELDS 8-10 Three-digit event code
FIELDS 11-12 Area Number
FIELDS 13-15 Zone Number
FIELD 16 Checksum
LOOP EVENTS & ZONE EVENTS
DMP PANEL MESSAGE
SERIAL 3 PROTOCOL CONTACT ID
EVENT DEFINITION SUB-MESSAGE CID CODE DEFINITION
ALARMS
FIRE TYPE A or R FI 110
FIRE - Fire Alarm - ZZZ
or RESTORE - Fire Alarm - ZZZ
CO TYPE A or R CO 162
CO - CO ALarm - ZZZ
or RESTORE - CO Alarm - ZZZ
DAY OR NIGHT TYPE A or R BU or BL 135
BURG - Entry/EXIT - ZZZ
or RESTORE - Entry/EXIT - ZZZ
SUPERVISORY TYPE A or R SV 200
SUPER - Fire Supervisory - ZZZ
or RESTORE - Fire Supervisory - ZZZ
PANIC TYPE A or R PN 120
PANIC - Panic - ZZZ
or RESTORE - Panic - ZZZ
EMERGENCY TYPE A or R EM 100
EMERG - Personal Emergency - ZZZ
or RESTORE - Personal Emergency - ZZZ
AUXILIARY 1/2 TYPE A or R A1 or A2 140
ALARM - General Alarm - ZZZ
or RESTORE - General ALARM - ZZZ
TROUBLES
OR FAULTS
FIRE TYPE T or W FI 373 TROUBLE - Fire Loop - ZZZ
CO TYPE T or W FI 380 TROUBLE - Sensor Trouble - ZZZ
OTHER TYPES T or W FI 370 TROUBLE - Protection Loop - ZZZ
ALL TYPES
FORCE ARM B FI 573 BYPASS - Burglary Bypass - ZZZ
LOW BATTERY D FI 384 TROUBLE - RF Sensor BAttery - ZZZ
MISSING H FI 381 TROUBLE - RF Sensor Supervisory - ZZZ
BYPASS OR RESET X or Y FI 570
BYPASSED - Zone Bypass - ZZZ
or RESTORE - Zone Bypass - ZZZ
A = Alarm
R = Restore
T = Trouble
W = Fault
X = Bypass
Y = Reset
