Faults & Troubleshooting:
Event
Code
Description
Possible Cause
Resolution
96112
Gas Alarm Level 1
Gas Release above Alarm Level 1.
Determine release
point
96113
Gas alarm Level 2
Gas Release above Alarm Level 2.
Determine release
point
96110
Analysis Mode
Analysis Mode
None needed
96111
TWA Cycle Complete
TWA Cycle Complete
None needed
96104
Cannot Get Background Values
Communication issue between optic
block and PC.
1. Power cycle
analyzer 2. Press
verify optics
3. Verify background
is within range in
system screen
4. Refer to optic
troubleshooting
procedure
96105
High Background
Background value is out of range.
1. Power cycle
analyzer 2. Press
verify optics
3. Verify background
is within range in
system screen
4. Refer to optic
troubleshooting
procedure
96107
PLC Comm. Error
Communication issue between PC and
PLC.
1. Power cycle the
CL96 2. If
issue reoccurs contact
DOD Technologies,
Inc.
96108
Optic Calibration Required
Optic system is unable to calibrate
automatically
1. Refer to the optic
cleaning procedure.
96109
Gas Configuration Error
System is unable to locate the files
required to detect the gas family
selected.
1. Remove the rear
panel 2. Verify the
USB thumb drive is
connected properly
3. Power cycle the
CL96
